Grundfos SP2A-9 4″ Submersible Pump (single phase)
Original price was: £1,124.00£1,348.80.£899.20£1,079.04Current price is: £899.20£1,079.04. Excl. VATInc. VAT
Grundfos SP2A-9 4″ submersible borehole pump with 240V 1Ph 50Hz, 0.37kW direct coupled 2900rpm electric motor.
The range of SP single phase pumps require the relevant SA-CSIR MS402 1×200-240V/50Hz control box to operate and to protect the warranty.
ALL PUMPS ARE SUPPLIED WITH 2 YEAR WARRANTY.
Product number: 09002E09
We supply the whole range of GRUNDFOS borehole/well pumps. Please contact us for a price if you require a model that is not shown.
| Weight | 12.73 kg |
|---|---|
| Rated flow: | 2 m³/h |
| Rated head: | 36 m |
| Motor version: | T40 |
| Return valve: | YES |
| Pump Materials: | Stainless steel |
| Motor Materials: | Stainless steel |
| Size of connection: | 1 1/4 inch |
| Motor diameter: | 4 inch |
| Minimum borehole diameter: | 105 mm |
| Motor type: | MS402 – CSIR |
| Rated voltage: | 1 x 240 V |
| Rated current: | 3.8 A |
| Starting current: | 380 % |
| Cos phi - power factor: | 0.77 |
| Rated speed: | 2860 rpm |
| Start. method: | direct-on-line |
| Length of cable: | 1.7 m |
| Power cable type: | FLAT |
| Minimum efficiency index, MEI ≥: | 0.70 |
| Net weight: | 11.3 kg |
| Gross weight: | 12.7 kg |
| Shipping volume: | 0.016 m³ |
| Country of origin: | GB |
| Custom tariff no.: | 84137029 |
